Type | Model | Type | Model | Type | Model | Type | Model | ||||
Tube(mm | Female (R) | Tube (inch) | Female (R) | Tube (inch) | Female (NPT) | Tube(mm) | Female (NPT) | ||||
EPHF04-M5 | 04 | M5 | EPHF5/32-01 | 5/32 | 1/8 | EPHF5/32-N01 | 5/32 | 1/8 | EPHF04-N01 | 04 | 1/8 |
EPHF04-M6 | 04 | M6 | EPHF5/32-02 | 5/32 | 1/4 | EPHF5/32-N02 | 5/32 | 1/4 | EPHF04-N02 | 04 | 1/4 |
EPHF04-01 | 04 | 1/8 | EPHF3/16-01 | 3/16 | 1/8 | EPHF3/16-N01 | 3/16 | 1/8 | EPHF06-N01 | 06 | 1/8 |
EPHF04-02 | 04 | 1/4 | EPHF3/16-02 | 3/16 | 1/4 | EPHF3/16-N02 | 3/16 | 1/4 | EPHF06-N02 | 06 | 1/4 |
EPHF06-M5 | 06 | M5 | EPHF1/4-01 | 1/4 | 1/8 | EPHF1/4-N01 | 1/4 | 1/8 | EPHF06-N03 | 06 | 3/8 |
EPHF06-M6 | 06 | M6 | EPHF1/4-02 | 1/4 | 1/4 | EPHF1/4-N02 | 1/4 | 1/4 | EPHF06-N04 | 06 | 1/2 |
EPHF06-01 | 06 | 1/8 | EPHF1/4-03 | 1/4 | 3/8 | EPHF1/4-N03 | 1/4 | 3/8 | EPHF08-N01 | 08 | 1/8 |
EPHF06-02 | 06 | 1/4 | EPHF1/4-04 | 1/4 | 1/2 | EPHF1/4-N04 | 1/4 | 1/2 | EPHF08-N02 | 08 | 1/4 |
EPHF06-03 | 06 | 3/8 | EPHF5/16-01 | 5/16 | 1/8 | EPHF5/16-N01 | 5/16 | 1/8 | EPHF08-N03 | 08 | 3/8 |
EPHF06-04 | 06 | 1/2 | EPHF5/16-02 | 5/16 | 1/4 | EPHF5/16-N02 | 5/16 | 1/4 | EPHF08-N04 | 08 | 1/2 |
EPHF08-01 | 08 | 1/8 | EPHF5/16-03 | 5/16 | 3/8 | EPHF5/16-N03 | 5/16 | 3/8 | EPHF10-N01 | 10 | 1/8 |
EPHF08-02 | 08 | 1/4 | EPHF5/16-04 | 5/16 | 1/2 | EPHF5/16-N04 | 5/16 | 1/2 | EPHF10-N02 | 10 | 1/4 |
EPHF08-03 | 08 | 3/8 | EPHF3/8-01 | 3/8 | 1/8 | EPHF3/8-N01 | 3/8 | 1/8 | EPHF10-N03 | 10 | 3/8 |
EPHF08-04 | 08 | 1/2 | EPHF3/8-02 | 3/8 | 1/4 | EPHF3/8-N02 | 3/8 | 1/4 | EPHF10-N04 | 10 | 1/2 |
EPHF10-01 | 10 | 1/8 | EPHF3/8-03 | 3/8 | 3/8 | EPHF3/8-N03 | 3/8 | 3/8 | EPHF12-N01 | 12 | 1/8 |
EPHF10-02 | 10 | 1/4 | EPHF3/8-04 | 3/8 | 1/2 | EPHF3/8-N04 | 3/8 | 1/2 | EPHF12-N02 | 12 | 1/4 |
EPHF10-03 | 10 | 3/8 | EPHF1/2-01 | 1/2 | 1/8 | EPHF1/2-N01 | 1/2 | 1/8 | EPHF12-N03 | 12 | 3/8 |
EPHF10-04 | 10 | 1/2 | EPHF1/2-02 | 1/2 | 1/4 | EPHF1/2-N02 | 1/2 | 1/4 | EPHF12-N04 | 12 | 1/2 |
EPHF12-01 | 12 | 1/8 | EPHF1/2-03 | 1/2 | 3/8 | EPHF1/2-N03 | 1/2 | 3/8 | |||
EPHF12-02 | 12 | 1/4 | EPHF1/2-04 | 1/2 | 1/2 | EPHF1/2-N04 | 1/2 | 1/2 | |||
EPHF12-03 | 12 | 3/8 | |||||||||
EPHF12-04 | 12 | 1/2 |
