Type | Model | Type | Model | Type | Model | Type | Model | ||||
Tube （mm） | Male （R） | Tube (inch） | Male（R） | Tube (inch） | Male （NPT） | Tube （mm） | Male （NPT） | ||||
TSC04-M5 | 04 | M5 | TSC5/32-01 | 5/32 | 1/8 | TSC5/32-N01 | 5/32 | 1/8 | TSC04-N01 | 04 | 1/8 |
TSC04-M6 | 04 | M6 | TSC5/32-02 | 5/32 | 1/4 | TSC5/32-N02 | 5/32 | 1/4 | TSC04-N02 | 04 | 1/4 |
TSC04-01 | 04 | 1/8 | TSC3/16-01 | 3/16 | 1/8 | TSC3/16-N01 | 3/16 | 1/8 | TSC06-N01 | 06 | 1/8 |
TSC04-02 | 04 | 1/4 | TSC3/16-02 | 3/16 | 1/4 | TSC3/16-N02 | 3/16 | 1/4 | TSC06-N02 | 06 | 1/4 |
TSC06-M5 | 06 | M5 | TSC1/4-01 | 1/4 | 1/8 | TSC1/4-N01 | 1/4 | 1/8 | TSC06-N03 | 06 | 3/8 |
TSC06-M6 | 06 | M6 | TSC1/4-02 | 1/4 | 1/4 | TSC1/4-N02 | 1/4 | 1/4 | TSC06-N04 | 06 | 1/2 |
TSC06-01 | 06 | 1/8 | TSC1/4-03 | 1/4 | 3/8 | TSC1/4-N03 | 1/4 | 3/8 | TSC08-N01 | 08 | 1/8 |
TSC06-02 | 06 | 1/4 | TSC1/4-04 | 1/4 | 1/2 | TSC1/4-N04 | 1/4 | 1/2 | TSC08-N02 | 08 | 1/4 |
TSC06-03 | 06 | 3/8 | TSC5/16-01 | 5/16 | 1/8 | TSC5/16-N01 | 5/16 | 1/8 | TSC08-N03 | 08 | 3/8 |
TSC06-04 | 06 | 1/2 | TSC5/16-02 | 5/16 | 1/4 | TSC5/16-N02 | 5/16 | 1/4 | TSC08-N04 | 08 | 1/2 |
TSC08-01 | 08 | 1/8 | TSC5/16-03 | 5/16 | 3/8 | TSC5/16-N03 | 5/16 | 3/8 | TSC10-N01 | 10 | 1/8 |
TSC08-02 | 08 | 1/4 | TSC5/16-04 | 5/16 | 1/2 | TSC5/16-N04 | 5/16 | 1/2 | TSC10-N02 | 10 | 1/4 |
TSC08-03 | 08 | 3/8 | TSC3/8-01 | 3/8 | 1/8 | TSC3/8-N01 | 3/8 | 1/8 | TSC10-N03 | 10 | 3/8 |
TSC08-04 | 08 | 1/2 | TSC3/8-02 | 3/8 | 1/4 | TSC3/8-N02 | 3/8 | 1/4 | TSC10-N04 | 10 | 1/2 |
TSC10-01 | 10 | 1/8 | TSC3/8-03 | 3/8 | 3/8 | TSC3/8-N03 | 3/8 | 3/8 | TSC12-N01 | 12 | 1/8 |
TSC10-02 | 10 | 1/4 | TSC3/8-04 | 3/8 | 1/2 | TSC3/8-N04 | 3/8 | 1/2 | TSC12-N02 | 12 | 1/4 |
TSC10-03 | 10 | 3/8 | TSC1/2-01 | 1/2 | 1/8 | TSC1/2-N01 | 1/2 | 1/8 | TSC12-N03 | 12 | 3/8 |
TSC10-04 | 10 | 1/2 | TSC1/2-02 | 1/2 | 1/4 | TSC1/2-N02 | 1/2 | 1/4 | TSC12-N04 | 12 | 1/2 |
TSC12-01 | 12 | 1/8 | TSC1/2-03 | 1/2 | 3/8 | TSC1/2-N03 | 1/2 | 3/8 | |||
TSC12-02 | 12 | 1/4 | TSC1/2-04 | 1/2 | 1/2 | TSC1/2-N04 | 1/2 | 1/2 | |||
TSC12-03 | 12 | 3/8 | |||||||||
| TSC12-04 | 12 | 1/2 | |||||||||
